Milling & drilling capabilities
- Manual & CNC Milling Machines
- CNC Machining Centers
- Custom Parts Manufacturing
- 24/7 Emergency Service
Milling/Drilling
Frontline's full machine shop combines manual and CNC milling machines with CNC centers and experienced machinists and programmers for in-house milling and drilling work.
Service overview
In-house machining for repair and custom work
Full machine-shop capability and experienced machinists and programmers support milling and drilling for repair and custom work.
CNC milling machines
Doosan Mynx 6500 / 50 II
- Type:
- CNC mill
- Capacity:
- 2,200 lbs.
- X axis travel:
- 50.0″
- Y axis travel:
- 26.4″
- Z axis travel:
- 24.6″
Takumi VIIA
- Type:
- CNC mill
- ATC:
- 24
- X axis travel:
- 32.0″
- Y axis travel:
- 20.0″
- Z axis travel:
- 22.0″
Doosan VM960L
- Type:
- CNC mill
- X axis travel:
- 94.4″
- Y axis travel:
- 37.7″
- Z axis travel:
- 31.4″
Manual milling machines
Acer
- Type:
- Manual mill
- Working surface:
- 49″ × 9″
- Cross travel:
- 12″
- Vertical knee travel:
- 16″
- Ram travel:
- 12″
- Head tilt:
- 45 deg. Front to Back
- Quantity:
- 2
Bridgeport — Single Axis
- Type:
- Manual variable speed mill
- Table size — Y:
- 10″
- Table size — X:
- 50″
- Table size — Z:
- 20″
- Quantity:
- 2
Victor — 2 Axis Power Feed
- Type:
- Manual variable speed mill
- Table size:
- 10′ × 50″
- Spindle taper:
- R8
Acer — 3 Axis Power Feed
- Type:
- Manual mill
- Table size — Y:
- 20″
- Table size — X:
- 31.5″
- Table size — Z:
- 20.87″
24 / 7 support
Need milling or drilling support?
Contact our team for machining support, emergency service or a quote.
